Power Shock B 500 plus

visual check for fence insulation and battery voltage

Extremely robust housing with innovative locking technology

allows for optional operation with 12 V battery – with deep discharge protection

Fence control LED and separate battery warning indicator

Ref. no.	PU	Pallet
372030	1	54 PAL

Model	Ref. no.	Stored Energy	max. discharge energy	max. voltage	Voltage in Open Circuit	Voltage at 500 Ohms	theoretical fence length as per VDE	max. fence length without vegetation	max. fence length with medium vegetation	max. fence length with high vegetation	Qty 1 m earth posts	Power Consumption
B 500 plus	372030	0.64 J	0.5 J	9,000 V	9,000 V	3,700 V	16 km	9 km	6 km	1.8 km	1	17 mA - 66 mA

1 x fence unit

1 x earth rod

1 x fence / ground connector cable

1 x warning sign
